Vertex with 3D regulation External drawer, height 93mm, 40kg, depth 350mm, Steel, White painted

3185012 / 8432393308913
New
DepthPackagingFinishingSKU
2701 KIT
White painted
3186712
3001 KIT
White painted
3186412
3501 KIT
White painted
3185012
4001 KIT
White painted
3186512
4501 KIT
White painted
3185112
5001 KIT
White painted
3185212
5501 KIT
White painted
3186912
3501 KIT
Silver painted
3185025
3001 KIT
Silver painted
3186425
4001 KIT
Silver painted
3186525
4501 KIT
Silver painted
3185125
5001 KIT
Silver painted
3185225
2701 KIT
Anthracite grey
3186735
3001 KIT
Anthracite grey
3186435
3501 KIT
Anthracite grey
3185035
4001 KIT
Anthracite grey
3186535
4501 KIT
Anthracite grey
3185135
5001 KIT
Anthracite grey
3185235
5501 KIT
Anthracite grey
3186935

Product features

  • Kit of fittings needed to assemble an exterior drawer with a height of 93 mm and depth of 350 mm, apart from the front, back and bottom.
  • Sized for a board thickness of 16 mm for the bottom and back of the drawer.
  • Synchronized total extraction runners, with soft closing and load capacity of 40 kg.
  • It has a 3D front adjustment: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm.
  • Made of white painted steel.

Components

1 pair of runners, 1 set of sides, 1 set of hooks for frontal drawer, screws

Vertex Kit for kitchen and bathroom drawer with all the necessary elements for its assembly. It is the optimal solution for your kitchen, bathroom or wardrobe furniture with an elegant design. Each kit is made up of all the elements necessary for mounting an external drawer of 93mm height, sized for a board thickness of 16mm for the bottom and back of the drawer. Includes: two sides, one set of soft-close runners, one set of covers and drawer front hooks.

The metal sides are made of steel with anthracite painted finish and allow the drawer front to be adjusted a 3D front: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm. The guides are total extraction with soft closing and allow a maximum load of 40 Kg for the drawer.

You will only need the boards cut to the correct dimensions for the bottom, the back and the front of the drawer.

Documentation

Frequently asked questions


The following video shows how to assemble such a box in a simple way:
