1 pair of runners, 1 set of sides, 1 set of hooks for frontal drawer, screws

Vertex Kit for kitchen and bathroom drawer with all the necessary elements for its assembly. It is the optimal solution for your kitchen, bathroom or wardrobe furniture with an elegant design. Each kit is made up of all the elements necessary for mounting an external drawer of 178mm height, sized for a board thickness of 16mm for the bottom and back of the drawer. Includes: two sides, one set of soft-close runners, one set of covers and drawer front hooks.

The metal sides are made of steel with anthracite painted finish and allow the drawer front to be adjusted a 3D front: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm. The guides are total extraction with soft closing and allow a maximum load of 40 Kg for the drawer.

You will only need the boards cut to the correct dimensions for the bottom, the back and the front of the drawer.

The Vertex drawer kit provides all the necessary components to assemble drawers with an elegant and functional design. This kit includes metal side ribs with an anthracite grey finish, soft-close runners, trim covers and drawer front fixings. It offers 3D adjustment allowing vertical adjustments of ±2 mm, horizontal adjustments of ±1 mm and tilts of -1.5/+4 mm. The full-extension slides withstand a maximum load of 40 kg, ensuring strength and functionality.

For manufacturers, this kit facilitates the creation of sophisticated and efficient storage systems, adapted to mass production needs.

For manufacturers, this kit facilitates the creation of sophisticated and efficient storage systems, adapted to mass production needs.

Wholesalers and distributors will be able to include this product in their catalogues as an integral solution that combines design and functionality, ensuring high turnover.

Carpenters and small workshops will appreciate its simple installation, which allows them to achieve high quality results in customised projects.

E-commerce and retailers will be able to position this kit as a modern and complete solution, ideal for customers looking to optimise their spaces with quality technical furniture.

The following video shows how to assemble such a box in a simple way:

The 178 mm Vertex drawer offers greater storage capacity, allowing larger items to be stored without compromising accessibility or the stability of the unit.

The 3D adjustment allows precise adjustment of the drawer front in three directions: ±2 mm vertically by means of an eccentric, ±1 mm horizontally and an inclination of +1.5/-4 mm, facilitating perfect alignment.

It is available in depths of 350 mm, 400 mm, 450 mm, 500 mm and 550 mm, with finishes in white painted, aluminium painted and anthracite grey.

This drawer supports up to 40 kg load and features synchronised full-extension slides with soft closing, guaranteeing smooth and silent sliding.

The cabinet must have a board thickness of 16 mm at the bottom and back of the drawer to ensure stable installation and precise adjustment of the adjustment system.

At Emuca, we make it easy for you. Here you can download this Excel file that will help you configure your drawer unit step by step. Simply enter the module measurements (height, thickness, overlap, etc.) and specify how many drawers you want. This file allows you to:

• Automatically calculate the machining dimensions of the drawer fronts (H1, H2, H3...) (mm).
• Determine the height of each drawer front (mm).
• And obtain the machining dimensions required to manufacture the drawer fronts (X, Y) (mm).

It also includes visual representations so you can check the result and avoid errors. Ideal for carpenters, designers or DIY enthusiasts who want a practical and accurate solution.

If a warning message appears when you open the Excel file, close the file. Right-click on the downloaded file and select Properties. At the bottom of the window, tick the box Unblock. Click Apply and then OK. You can now open the file.
