Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-Primary

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-1

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-2

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-3

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-4

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-5

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-6

Vertex with 3D regulation External drawer, height 131mm, 40kg, board thickness of 18mm, depth 450mm, Steel, Anthracite Grey-7

Depth	Packaging	Finishing	SKU
350	1 KIT	Anthracite grey	3213735
400	1 KIT	Anthracite grey	3214035
450	1 KIT	Anthracite grey	3204635
500	1 KIT	Anthracite grey	3214335

Product features

Kit of fittings needed to assemble an exterior drawer with a height of 131 mm and depth of 450 mm, apart from the front, back and bottom.
Sized for a board thickness of 18 mm for the bottom and back of the drawer.
Synchronized total extraction runners, with soft closing and load capacity of 40 kg.
It has a 3D front adjustment: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm.
Made of anthracite gray painted steel.

SKU	3204635
EAN	8432393323022
Model	Vertex
Format	Kit
Extension	Total
Opening	Normal
Latch type	Soft close
Adjustment	3D regulation
Load	40 kg
Depth	450
Board thickness	18 mm
Height	131 mm
Finishing	Anthracite grey
RAL	approx. RAL 7043
Material	Steel
Dimensions	13.1 x 1.3 x 45 cm

Components

1 pair of runners, 1 set of sides, 1 set of hooks for frontal drawer, screws

Product description

Vertex Kit for kitchen and bathroom drawer with all the necessary elements for its assembly. It is the optimal solution for your kitchen, bathroom or wardrobe furniture with an elegant design. Each kit is made up of all the elements necessary for mounting an external drawer of 131mm height, sized for a board thickness of 18mm for the bottom and back of the drawer. Includes: two sides, one set of soft-close runners, one set of covers and drawer front hooks.

The metal sides are made of steel with anthracite painted finish and allow the drawer front to be adjusted a 3D front: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm. The guides are total extraction with soft closing and allow a maximum load of 40 Kg for the drawer.

You will only need the boards cut to the correct dimensions for the bottom, the back and the front of the drawer.

Documentation

Assembly instructions

Frequently asked questions

How can I easily configure my Vertex drawer unit?

At Emuca, we make it easy for you. Here you can download this Excel file that will help you configure your drawer unit step by step. Simply enter the module measurements (height, thickness, overlap, etc.) and specify how many drawers you want. This file allows you to: Automatically calculate the machining dimensions of the drawer fronts (H1, H2, H3...) (mm). Determine the height of each drawer front (mm). And obtain the machining dimensions required to manufacture the drawer fronts (X, Y) (mm). It also includes visual representations so you can check the result and avoid errors. Ideal for carpenters, designers or DIY enthusiasts who want a practical and accurate solution. If a warning message appears when you open the Excel file, close the file. Right-click on the downloaded file and select Properties. At the bottom of the window, tick the box Unblock. Click Apply and then OK. You can now open the file.

Download document

What is the RAL code of the finishes of the sides of the Vertex drawer?

The RAL code of the anthracite grey finish of the sides of the Vertex drawer is approximately 7043. The RAL code of the grey finish of the sides of the Vertex drawer is approximately 7045. The RAL code of the white finish of the sides of the Vertex drawer is approximately 9003.

How do you assemble a Vertex 3D drawer with an extra slim design and soft closing in kitchen, bathroom and home furniture?

The following video shows how to assemble such a box in a simple way:
